This graphics-based web tool allows users to create customised cable assemblies using very detailed design characteristics including a selection of connector types, wire type, pin definitions, pin and cable labeling, cable bundling, length selection, sleeving comments and more.
The cable design tool has a built-in library of standard cable sets that can be used as the basis for customisation or cables can be designed from scratch. If a user gets stuck creating a cable, all they need to do is submit the semi-completed assembly and one of Pickering’s engineers will provide guidance through the complete process. When the customised cable assembly is finished, users just need to submit it for a quote.
The tool runs on all modern browsers and is fully supported on all major tablet operating systems.
